matlab-python程序互转

处理对比




Key Differences:

1. Matrix/Array Handling: Both MATLAB and Python (via NumPy) handle 1D arrays (vectors) similarly, yet the syntax for operations and indexing differs slightly.

Indexing: In MATLAB, array indexing starts at 1. In Python, indexing starts at 0.

Array Expansion (`hstack` vs Array Concatenation): MATLAB's `hstack` for horizontal concatenation corresponds to Python's array concatenation but differs in syntax and implementation.

Mathematical Expressions:

MATLAB uses direct mathematical notation suitable for documented equations, while the Python code uses NumPy for vector operations.

Looping:

The Python code explicitly slices the input array, adjusting for the delay by removing the first two elements before upsampling.

It uses NumPy for array operations and matplotlib for plotting.

MATLAB Original


```matlab


T = 1;


Fs = 2/T;


Ts = 1/Fs;


c_opt = [2.2 4.9 3 4.9 2.2];


t = 5T:T/2:5T;


x = 1./(1+((2/T)t).^2); % sampled pulse

equalized_x = filter(c_opt, 1, [x 0 0]); % since there will be a delay of two samples at the output

equalized_x = equalized_x(3:end);


figure(1)


stem(equalized_x)


figure(2)

stem(equalized_x(1:2:end)) % for downsampled equalizer output

```


Python Rewritten


```python


T = 1


Fs = 2/T


Ts = 1/Fs


c_opt = np.array([2.2,4.9,3,4.9,2.2])


t = np.linspace(5T, 5T, num=21)


x = 1/(1 + (2/T t)2)

x = np.hstack((x, np.zeros(2)))   Adjustment for delay in output

equalized_x = scipy.signal.lfilter(c_opt, [1], x)

equalized_x = equalized_x[2:]   Adjusted slicing to remove delayinducing elements

plt.figure(1)


plt.stem(equalized_x)


plt.figure(2)

plt.stem(equalized_x[::2])   For downsampled equalizer output

plt.show()


```


Key Points of the Revised Python Code:

The `.hstack()` equivalent is replaced using `np.hstack` for array concatenation, adjusting thezeros array for the delay effect correctly.

Explicit slicing to address the `delay` is altered to utilize Pythonic halfstep indexing for downsampling.

`scipy.signal.lfilter` is used directly without unnecessary array stacking, simplifying the process against the initial modification.

Conclusion:

This contrast showcases the adaptive nature of programming practices across languages, highlighting both similarities in handling mathematical operations and differences in syntax and array manipulation techniques.
